Modeling of power electronics equipment (FACTS) in load flow and stability programs: a representation guide for power system planning and analysis

The document covers the following devices : SVC, STATCOM, BESS, SMES, TCSC, SSSC, TCPAR, UPFC, HVDC, SCDC. Each section has been written so that it can be read independently from each other; A survey on existing tools and practices on FACTS is given before the descriptions of the various FACTS device models in the succeeding sections.
