Guide to Develop Real-Time Simulation Models for HVDC Operational Studies

This Technical Brochure provides practical guidelines for the development of real-time simulation models for HVDC operational studies to evaluate the performance of HVDC Control and Protection (C&P) systems. The first part of the Brochure introduces some typical studying scenarios for HVDC systems and their real-time simulation modelling requirements. The detailed modelling techniques for an entire simulation environment are discussed in the second part, involving HVDC main circuit models, HVDC C&P models and AC system representations. Several models with different accuracy for one device or C&P system and the guidance for model selection are present in the brochure, as well as the detailed and practical methods used for verifying real-time simulaiton models. The last part of TB summarizes…
