High-Frequency Transformer and Reactor Models for Network Studies - Part D: Model interfacing and specifications

Part D – Model specification and interfacing

The reliable and safe operation of the transformer requires that the dielectric stresses imposed by transient overvoltages are kept within acceptable limits. Suitable transformer models for electromagnetic transient (EMT) studies can be of type white-box, black-box, or grey-box. The white-box and black-box models can have alternative formulations, and they comprise of a large number of parameters. The lack of standard model formats is therefore a major obstacle when transferring models between parties. CIGRE JWG A2/C4.52 proposes data formats that could be used for representing the most common model formulations, including pole-residue models and state-space models. Pseudo-codes are provided that permit to generate data files, and simple…
