Guidelines for the preparation of “connection agreements” or “Grid Codes” for multi-terminal DC schemes and DC Grids

In the light of recent advancement of HVDC technology and the prospect of DC grid projects a need to address the required guide lines to develop the DC grid codes has arisen. Grid Codes or network codes are a set of rules and guidelines that govern a power system environment with multiple stakeholders, which describe e.g. the technical requirements that the equipment must fulfil in order to be integrated in the system and the rules and guidelines for interactions between the systems and stakeholders under steady state or abnormal operation conditions. This brochure provides recommendations on the models of interactions between the stakeholders and activities from planning to operation including technical aspects of planning, building and operation of a DC grid. Based on these…
