General guidelines for HVDC electrode design

HVDC electrodes have traditionally been installed on HVDC transmission systems to provide a low resistance current return path during both monopolar and bipolar operation using the earth and/ or sea as the conductive medium. HVDC electrodes are in general less costly and have lower losses than dedicated metallic return conductors. Environmental concerns related to electrode operation have become more prominent in recent years due to greater public awareness of potential impacts, tighter environmental approval processes and increasing numbers of HVDC projects. While the environmental approval process can be challenging, the longtime successful operation of older electrodes indicates many of the potential environmental impacts from electrodes can be minimized or eliminated either by…
